What Should We Do If The Magnetic Pump Trips During Operation
TIME：2024-09-26 Author：admin Views：
What should we do if the magnetic pump trips after running for a period of time? Before finding a solution, we must first find out the cause. The common cause of pump tripping is overload operation.
As a high-safety level transportation equipment, if there is improper operation in daily use that causes abnormal operating parameters, the magnetic pump will automatically trigger the protection function to protect the pump. Next, we will sort out the causes and solutions of magnetic pump tripping.
Tripping caused by overload operation. Different magnetic pump models and specifications have specified operating parameters. If the parameters such as head flow are forced to exceed the standard operation, the current will rise, causing tripping.
Solution: To avoid this situation, the flow control should be within the performance specification range by adjusting the valve opening, or the pump head should be reduced.
There may be problems with the motor. If the use environment is harsh and the maintenance of the pump motor is not paid attention to, the motor may be damp and cause excessive current, or use non-original motors, and the pump itself is of poor quality, resulting in unstable voltage and tripping.
Solution: It is recommended to pay attention to the protection of the motor according to the relevant operating instructions, and avoid using non-matching motors.
Adjustment caused by damage to the internal components of the pump body. Common problems include bending of the pump shaft, severe bearing wear, coupling deviation or too small clearance, etc.
Solution: It is necessary to gradually check the internal components and repair or replace new parts as needed to solve the problem.
In short, the reasons for the tripping of the magnetic pump are the above-mentioned ones. After checking the specific reasons, targeted treatment can be carried out. We recommend that equipment operators strengthen their knowledge of magnetic pump operation to avoid failures caused by improper operation.
As a high-safety level transportation equipment, if there is improper operation in daily use that causes abnormal operating parameters, the magnetic pump will automatically trigger the protection function to protect the pump. Next, we will sort out the causes and solutions of magnetic pump tripping.
Tripping caused by overload operation. Different magnetic pump models and specifications have specified operating parameters. If the parameters such as head flow are forced to exceed the standard operation, the current will rise, causing tripping.
Solution: To avoid this situation, the flow control should be within the performance specification range by adjusting the valve opening, or the pump head should be reduced.
There may be problems with the motor. If the use environment is harsh and the maintenance of the pump motor is not paid attention to, the motor may be damp and cause excessive current, or use non-original motors, and the pump itself is of poor quality, resulting in unstable voltage and tripping.
Solution: It is recommended to pay attention to the protection of the motor according to the relevant operating instructions, and avoid using non-matching motors.
Adjustment caused by damage to the internal components of the pump body. Common problems include bending of the pump shaft, severe bearing wear, coupling deviation or too small clearance, etc.
Solution: It is necessary to gradually check the internal components and repair or replace new parts as needed to solve the problem.
In short, the reasons for the tripping of the magnetic pump are the above-mentioned ones. After checking the specific reasons, targeted treatment can be carried out. We recommend that equipment operators strengthen their knowledge of magnetic pump operation to avoid failures caused by improper operation.
-THE END-
